Push Interruption Diagnostics

Last updated: 2019-10-18 11:35:03

PDF

Contents：

Scenario

With push interruption diagnostics, you can quickly check the record of live push interruptions and their reasons.

Prerequisites

There is an interruption in live push under the current Tencent Cloud account.

Steps

After the live push is interrupted, select Auxiliary Tools > Interruption Diagnosis in the left sidebar to enter the push interruption diagnostics page.

Here, path is the AppName in the push address, and streamname is the StreamName in the push address.

The error codes and corresponding reasons are listed in the table below:

Error Code Reason
0 Unknown error.
1 The push client actively stopped the push.
2 The push client actively stopped the push.
3 The push client actively stopped the push.
4 The push client actively stopped the push.
5 Internal error in the LVB system.
6 Exception with the RTMP protocol content.
7 The size of a single RTMP frame exceeds the maximum value allowed by the configuration.
8 The system actively disconnected the push as there was no data for a long time.
9 Internal error in the LVB system.
10 The proxy layer received an interruption command.
11 Internal error in the LVB system.
12 Exception with the push linkage network.
13 Exception with the push linkage network.
14 Exception with the push linkage network.
15 Exception with the push linkage network.
16 Internal error in the LVB system.
17 Exception with the push linkage network.
18 100 Internal error in the LVB system.
101 Internal error in the LVB system.
102 Internal error in the LVB system.
103 Internal error in the LVB system.
104 Internal error in the LVB system.
200 Failed to get the customer information corresponding to the push link.
201 Your LVB service has been disabled.
202 You LVB service has been temporarily disabled due to arrears in your account. Please top up promptly.
203 Your LVB service has been forcibly disabled.
300 Push with an IP address is not allowed.
301 Unable to identify the push domain name.
302 The push domain name is invalid.
303 The push domain name is disabled.
304 The push application name is disabled.
305 The push stream name is currently forbidden.
306 The access mode is channel mode, but the corresponding push channel has not been created yet.
307 The access mode is channel mode, but the current push channel has been disabled.
308 The push stream name contains invalid characters.
309 The push application name contains invalid characters.
400 The push client IP is in the blacklist.
401 The push client IP is not in the whitelist.
500 The push does not have an expiration time parameter.
501 The parameter value of the expiration time has expired.
502 The push does not have an authentication parameter.
503 Authentication parameter verification failed.
600 The current number of pushes exceeds the maximum value allowed by the configuration.
601 The number of pushes corresponding to the current stream name exceeds the maximum value allowed by the configuration.
19 Third-party authentication failed.
20 The system actively disconnected the push as there was no data for a long time.
21 100 A request from the client to stop the push was received.
101 A request from the client to forbid the playback was received.
102 A new push link was received to replace the current push.
22 Unknown reason.
23 Exception with the RTMP protocol content.
24 Internal error in the LVB system.
25 Unknown reason.
26 Unknown reason.
27 Unknown reason.
28 Unknown reason.
29 Unknown reason.
30 Unknown reason.
31 Unknown reason.
32 Unknown reason.
33 Exception with the RTMP AMF data.
34 Unknown reason.
35 The push client actively stopped the push.

LVB also provides an API for queries. For more information, see Querying Push Interruption Events.
